P. 43

Alternative Application Types
                                                                                        For Different Designs
                                                                                        Linera glass railing system can be mounted in 3 different ways: surface-mounted, forehead-mounted and
                                                                                        ground-mounted. Apart from the use of one piece, it offers the option of using split jaws.


                                                                                        Whether you use it indoors or outdoors,
                                                                                        the decision is yours!

                                                                                        With its special design that can be adapted for glass with a thickness of 16.76 to 21.52 mm, Linera is suitable
                                                                                        for both indoor and outdoor use. Linera allows different French Balcony applications to be made between the
                                                                                        walls or in front of the walls.












        Glass Railing System
        Linera


        Linera is an internationally certificated & patented design that provides easy production and installation. This
        system can withstand large force (3,4kN) and impact loads (50kg). In other words, quality, safety, durability,
        beauty, functionality, feasibility, creativity, and affordability are the genetic codes of Linera. So choose
        any application area, a stairway, terrace, balcony or a stadium... as Linera can meet all technical and safety
        requirements.
        European Test Certificate!
        Durable and Strong!                                                                   Technical Details     Description
        It has been tested and approved by the European Independent Test Institutes that the patented Linera glass
        balustrade system can withstand loads up to 3.4 kN                                    Height                Max. 1300 mm
                                                                                              Module Width          Max. 1100 mm
        Meet the Special Adjustment Mechanism
        For Top Glass Alignment!                                                              Glass Type            Laminated Glass | Tempered Laminated Glass
        The special Albert Genau design, which provides inward-outward adjustment of the glass ends up with a total   Glass Thickness  8.8 mm / 10.10 mm
        of 4 cm against ground and glass torsion errors, providing convenience for glass alignment.  Installation   Top-Mount, Face-Mount, In-Floor
                                                                                                                    Partial (150 mm and 300 mm)
        With Smart Led Integration                                                            Production Type       Linear ( 3000 mm)
        Let Your Space Reflect Your Light!                                                    LED Solutions         Optional
        Linera creates the ambience you want on your balcony with its smart LED light integration. It creates a stylish,
        elegant and special place for you.

        43
